Areas of application
- Single side grinding machines
- CNC processing machines
- Precision optical grinding machines
- Spherical grinding machines
- Centring machines
- Faceting machines
- Manual workstations
- Surface grinding machines
| CFS - 75 | Technical data |
|---|---|
| Filling volume | 75 L |
| Sedimentation sections | 2 |
| Supply pumps | 2 |
| Max. flow rate per pump [l/min] | 100 |
| Temperatur accuracy [℃] | ≤ 1 |
| Constant filtering[µm] | 5 |
| Fine filtering [µm] | 1 |
| Electric connection | 400V - 3Ph - 50Hz 220V - 1Ph - 50Hz 208V - 3Ph - 60Hz 208V - 1Ph - 60Hz |
| Emty weight [kg] | 112 |
| Dimensions [L x B x H cm³] | 82 - 49 - 117 |
| Inlet height 1 - EH 1 [cm] | 49 |
| Inlet height 2 - EH 2 [cm] | 44 |
PDF Download
Olga Stark
Internal Sales for Tools, Machines & Consumables
+49 (0)30 5858428 32
olga.stark@dopa-diatools.com
Jürgen Waidhas
Sales Engineer for Tools, Machines & Consumables
+49 (0)1624012599
juergen.waidhas@dopa-diatools.com
Mario Patraschkov
Head of Sales Tools, Machines & Consumables
+49 (0)30 5858428 31
mario@dopa-diatools.com
Please do not hesitate to contact us. We would gladly support you with our expertise and customize the machines to your needs.
